Mobiltherm 600系列
传热油
产品描述
传热油Mobiltherm高性能产品用于闭式间接加热装置。建议在各种工业过程中使用的冷油密封，间接加热和冷却系统。
传热油Mobiltherm制定由高度精炼的基础股票是抵抗热裂化和化学氧化。他们是非常热稳定，是一个非常长的使用寿命没有存款的形成或粘度增加的能力。
传热油Mobiltherm有良好的传热效率和粘度等，可以抽容易在启动和运行温度。他们表现出比热和热导率，提供更快速的散热。这些油的闪光点不会减少显着的服务，因为他们的抵抗热裂纹的工作温度，他们的建议。

Mobiltherm 600 Series

Heat transfer Oils

Product Description

Mobiltherm heat transfer oils are high performance products intended for use in closed indirect heating installations. They are recommended for use in cold-oil sealed, indirect heating and cooling systems in all kinds of industrial processes.

Mobiltherm heat transfer oils are formulated from highly refined base stocks that are resistant to thermal cracking and chemical oxidation. They are very thermally stable and are capable of an extremely long service life without deposit formation or viscosity increase.

Mobiltherm heat transfer oils have good heat transfer efficiency and their viscosities are such that they can be pumped readily at both start-up and operating temperatures. They demonstrate specific heat and thermal conductivities that provide more rapid heat dissipation. The flash points of these oils will not decrease significantly in service because of their resistance to thermal cracking at the operating temperatures for which they are recommended.

Features and Benefits

Mobiltherm oils are important members of the Mobil brand of specialty fluids that have gained a reputation for performance and reliability, even in severe applications. Modern refining techniques are a key factor in providing the excellent product features.

Mobiltherm 600 Series offer the following benefits:

Applications

Application Considerations: Mobiltherm heat transfer oils should not be mixed with other oils since this may impair the excellent thermal and oxidation stability resulting in a change in other properties, and complicate analyses aimed at determining useful oil life. If the oils are used above their recommended maximum temperatures, vapor lock may result unless the system is designed to operate at the higher temperature by pressurizing with an inert gas such as nitrogen. At higher temperatures, fluid life will be shortened because the rate of thermal degradation which increases markedly as temperatures rise above the recommended limit. In well-designed systems the temperature of the oil film surrounding the heating element should be about 15ºC to 30ºC above the bulk oil temperature. If higher than this, the service life of the oil may be shortened and sludge and coke may be deposited which would interfere with the heat transfer rates.

As with other mineral oils, Mobiltherm heat transfer oils should be used only in systems with forced circulation. Systems that depend on convection for circulation of the heat transfer medium do not provide a rapid enough flow to prevent local overheating and rapid deterioration of the oil. Further, these oils are not recommended for use in open systems where hot oil is exposed directly to the air. If they spray or escape from leakage points, hot Mobiltherm oils may spontaneously ignite.

Mobiltherm 600 series can be used in open and closed installations where the bulk oil temperature ranges are as outlined in the table below.

• Mobiltherm 603: Closed Systems (-15º C to 285º C), Open Systems (-15º C7 C to 150º C)
• Mobiltherm 605: Closed Systems (-12º C to 315º C), Open Systems (-12º C to 180º C)
• Mobiltherm 610: Open systems (-6°C to 250°C)
• Mobiltherm 611: Open systems (-6°C to 275°C)

Typical Properties
