美孚™格高系列
Polyalkylene Glycol（PAG）齿轮、轴承、压缩机润滑油
产品描述
美孚™格高系列润滑油是性能优越的齿轮、轴承、压缩机设计提供在效率方面的突出优势的油，油的使用寿命长，设备的防护。这些全合成，polyalkylene glycol（PAG）润滑剂的开发操作条件下使用的能力之外的其他合成润滑油和矿物油。他们的低凝点保证了优良的低温流动性。ISO 150至1000年级是NSF H1注册润滑油并符合标题21 CFR 178.3570的食品和药物管理局（美国）与食品偶尔接触的润滑剂。
-特殊环氧树脂/关键设备部件抗磨保护
一个高水平的微点蚀保护敏感的齿轮系统
在役中防止锈蚀和腐蚀
抗泡沫积累
优秀的润滑性内在这充分合成润滑油
低的牵引系数，从而提高能源效率和减少散装油/系统温度
-很好的热稳定性和氧化稳定性，以减少污泥的形成和沉积
特点和优点
全合成油的美孚格高系列是专为齿轮和烃类气体压缩应用优于矿物和PAO合成润滑油。在蜗杆齿轮中，这些油的独特属性允许更多的扭矩被穿通过减速器，而在许多情况下，降低运行油底壳的温度相关联的更长的密封，油和变速箱寿命。在气体压缩机，在美孚格高系列碳氢化合物的溶解度有限可以减少润滑油的稀释和增强设备保护。
功能相比其他矿物，合成，和PAG润滑油：
一般：有各种类型的PAG基础油。这些油的固有属性可能会有所不同，这取决于他们的制造中使用的原材料和工艺。功能，各种不同的PAG油包括牵引系数（能源效率）、热导率、溶解度与烃油吸引水趋势，低温性能。
效率高：埃克森美孚研究人员选择PAG基础油提供高水平的能源效率相对矿物，聚磷菌，和其他PAG油。这一点，再加上约10%以上的矿物和泡油的热导率增加，导致较低的工作温度和较长的元件寿命。
宽温度：美孚格高系列具有很高的可见光范围从170到285的ISO 68 ISO 1000。这导致了一个广泛的工作温度范围以外，矿物和润滑油。
防锈：PAG润滑油，它被设计成与烃油混溶，易吸收水比矿物或PAO油。由于在油中的高水的潜力，必须小心，以防止设备生锈的形成。美孚格高系列润滑油通过重大锈蚀试验如ASTM d665a和伯利恒钢铁防锈试验部分的A / B，在DIN 51802 EMCOR防锈试验用蒸馏水接收0,0评级。此外，他们表现出良好的黄色金属的相容性与ASTM D130试验1B评级。美孚格高系列是不推荐使用的地区，海水污染预计。
泡沫控制：泡沫控制是很重要的，特别是在“密封生活”的盒子里。美孚格高系列在所有三个序列的ASTM D 892泡沫试验提供了很好的结果。
极压抗磨：具有极压抗磨保护正确的融合是很重要的，尤其是在蜗轮含有铜和其他有色金属。润滑油格高系列节目在DIN 51354-2 FZG划伤测试12 +的典型结果优良的EP /抗磨保护，非常低的笼和FAG FE8试验DIN 51819-3磨损辊，和出色的微点保护在FVA 54微点蚀测试结果的›10高（ISO 320）。

Mobil Glygoyle™ Series

Polyalkylene Glycol (PAG) Gear, Bearing and Compressor Lubricant

Product Description

Mobil Glygoyle™ Series lubricants are superior performance gear, bearing and compressor oils designed to provide outstanding benefits in terms of efficiency, long oil life, and equipment protection. These fully synthetic, polyalkylene glycol (PAG) lubricants were developed for use under operating conditions beyond the capabilities of other synthetic lubricants and mineral oils. Their low pour points ensure excellent low-temperature fluidity. The ISO 150 to 1000 grades are NSF H1 registered lubricants and also comply with Title 21 CFR 178.3570 by the Food and Drug Administration (USA) for lubricants with incidental food contact.

- Exceptional EP/antiwear protection for critical equipment components

- A high level of micropitting protection for sensitive gear systems

- Protection against rust and corrosion in-service

- Resistance against foam buildup

- Excellent lubricity inherent to this fully synthetic lubricant

- Low traction coefficient resulting in increased energy efficiency and reduced bulk oil/system temperatures

- Very good thermal and oxidative stability to reduce sludge formation and deposits

Features and Benefits

The Mobil Glygoyle Series of fully synthetic oils is specifically designed to outperform mineral and PAO synthetic lubricants in gear and hydrocarbon gas compression applications. In worm gears, the unique properties of these oils allows for more torque to be put through the reducer while in many cases lowering the operating oil sump temperature correlating to longer seal, oil, and gearbox life. In gas compressors, the limited solubility of hydrocarbons in the Mobil Glygoyle Series allows for reduced lubricant dilution and enhanced equipment protection.
Features compared to other mineral, synthetic, and PAG lubricants:
General: There are various types of PAG base oils. The inherent properties of these oils can differ depending on the raw materials and processes used in their manufacture. Features that can differ among various PAG oils include their traction coefficient (energy efficiency), thermal conductivity, and solubility with hydrocarbon oils, tendency to attract water, and low temperature properties.
High Efficiency: ExxonMobil researchers have selected PAG base oils which provide high levels of energy efficiency relative to mineral, PAOs, and other PAG oils. This, coupled with an increased thermal conductivity of about 10% over mineral and PAO oils, leads to lower operating temperatures and longer component life.
Wide Temperatures: The Mobil Glygoyle Series has very high VIs ranging from 170 for the ISO 68 to 285 for the ISO 1000. This leads to a wide operating temperature range, beyond that of mineral and PAO lubricants.
Rust Protection: PAG lubricants, which are designed to be immiscible with hydrocarbon oils, tend to absorb water more than mineral or PAO oils. Because of the potential for high water-in-oil levels, care must be taken to prevent the formation of rust on equipment.  Mobil Glygoyle Series oils pass major rust tests such as the ASTM D665A and Bethlehem Steel rust test parts A/B, and receives 0,0 ratings in the DIN 51802 Emcor rust test with distilled water. In addition, they show good yellow metal compatibility with a 1B rating in the ASTM D130 test. Mobil Glygoyle Series is not recommended for use in areas where saltwater contamination is expected.
Foam Control: Foam control is important, especially in boxes that are "Sealed for Life". Mobil Glygoyle Series provides excellent results in all three sequences of ASTM D 892 Foam Test.
EP/antiwear: Having the right blend of EP/AW protection is important, especially in worm gears that contain bronze and other yellow metals. The Glygoyle Series of lubricants show excellent EP/antiwear protection with typical results of 12+ in the DIN 51354-2 FZG scuffing test, very low cage and roller wear in the DIN 51819-3 FAG FE8 test, and excellent micropitting protection with a result of ›10-high in the FVA 54 micropitting test (ISO 320).

Applications

The Mobil Glygoyle Series is specifically designed for the lubrication of worm gears, especially for heavy-duty, severe service applications, both in food-grade and non food-grade applications. Additionally, the product family has also proven to be an excellent lubricant for many types of industrial gears and anti-friction bearing applications under severe service conditions. Additionally, their poor miscibility with hydrocarbons makes the lower viscosity grades especially effective in hydrocarbon gas compression applications because of the reduced viscosity dilution that occurs in this application versus hydrocarbon based compressor oils.
The Mobil Glygoyle Series is used for the lubrication of filled for life gearboxes and heavy-duty worm gears, other industrial gearing in a wide variety of applications, lubrication of plain and rolling contact bearings, and most types of compressors.

Specific applications include:

- Filled for life gearboxes, especially high ratio/low-efficiency worm gears

- Worm gear applications such as those used in conveyers, escalators, material handling, press drives, packaging machinery, ski lifts, agitators and mixers

- Other gear and bearing applications in the cement, metalworking, plastics, food and textile finishing industries

- Gas Compression utilizing reciprocation, rotary, screw, and centrifugal type compressors in operating conditions beyond the capabilities of other synthetic lubricants and mineral oils
Application notes
Polyalkyleneglycol (PAG) based lubricants have some inherent excellent lubrication properties imparted by the PAG base oil. However, PAG based lubricants do have limitations with respect to compatibility with seal and coating materials, some varieties of light metal alloys and other lubricants.  Before applying any PAG lubricant, contact the orginal equipment manufacturer for specific advice on the application.
Compatibility with other lubricants
The Mobil Glygoyle Series is not compatible with mineral oils and most other synthetic lubricants.  Additionally, depending on the specific type of PAG base fluid, they may not be compatible with other PAG type lubricants. (e. g. Mobil Glygoyle No Series and Mobil Glygoyle ISO VG Series are not miscible). The Mobil Glygoyle Series is not generally recommended for use in systems previously filled with mineral oils or PAO based synthetic lubricants.  It is further recommended to check compatibility when topping up or replacing existing PAG fillings with Mobil Glygoyle Series, generally the preference is to avoid mixtures by draining, flushing and refilling.
When changing from mineral oil or other synthetic products to Mobil Glygoyle Series, it is critical to clean the system thoroughly and flush with suitable fluids prior to conversion. For further details please contact your ExxonMobil representative.
Water
Mobil Glygoyle Series oils, along with all PAG based lubricants, are hygroscopic and absorb more water than mineral oils or synthetic hydrocarbons before. Therefore extra care should be taken not to expose PAG oils to excessive moisture.  Due to their inherent high specific gravity, water does not drop to the bottom of reservoirs, but stays on top of the lubricant.
Seal compatibility
PAG based lubricants are not compatible with most standard seal materials used for mineral oils or synthetic hydrocarbons. Incompatible materials are likely to shrink or swell, thus causing severe leakage or seizure of the seal. When converting from mineral oil or synthetic hydrocarbons to Mobil Glygoyle Series, seal compatibility must be considered. FKM and VMQ are normally suitable for use with PAG.  NBR materials may be used but have restricted temperature range. In all cases, operating conditions and the variability of elastomer properties from different manufactures should be considered.  For best results, consult the equipment supplier or seal manufacturer for specific recommendations.
Light Metal Alloys
Mobil Glygoyle Series and PAG lubricants are well suited for gear applications with ferrous and most non ferrous materials.  However, Mobil Glygoyle Series and PAG lubricants are not recommended for use with light metal alloys containing Aluminum or Magnesium.  PAG lubricants can lead to increased wear when used with light metal alloys of this nature.  Please consult the original equipment manufacturer for additional information.
Other Materials
Paints, coatings, and some plastics are not suitable for use with PAG lubricants. In general two component paints (reactive paints, epoxy resins) are suitable for use for interior coatings in contact with the lubricant.  Otherwise, interiors in contact with the lubricant should be left uncoated.  Materials used for oil level gages, inspection doors etc., should preferably be made of natural glass or polyamide materials. Other transparent plastics, (e.g. Plexiglas), may deteriorate and crack under stress.

Specifications and Approvals

Typical Properties
