美孚™FM 101 FM 222润滑脂
产品描述
美孚™FM 101 FM 222是高性能多用途的产品专门设计用于食品加工机械的润滑。美孚FM 101 FM 222 CFR 178.3570组成的会议，要求制定21章，并且被NSF注册为H1类润滑剂。美孚FM 101和fm222在ISO 22000认证的设施，同时满足ISO 21469帮助确保维持最高水平的要求制造产品的完整性。
食品加工设备经常在各种各样的环境中工作，包括从烤箱到冷冻操作的极端温度，以及高水平的水，蒸汽和清洁剂的污染。美孚FM 101 FM 222开发的多用途润滑脂能够在这些环境中良好的润滑。美孚FM 101 FM 222的设计，具有优良的抗水性承受周期性的冲洗和清洗操作在食品加工行业频繁。防锈是该行业的一个关键属性。美孚FM 101和FM 222是一个优秀的防锈包装制定，工作在演唱会与抗水性能，将提供防锈保护。选择基础油加上优良的增稠剂剪切稳定性转化为一个能够提供润滑在很宽的范围内的速度，负载和温度。美孚FM 101和222还制定了处理各种荷载作用下，表现出良好的抗磨损和冲击载荷条件。
美孚FM 101和FM 222的设计，以满足全球许多性能和文化的要求，包括：
- NSF H1注册
DIN 51825 kpf1k - 20（为美孚FM 101）
DIN 51825 kpf2k-20（为美孚FM 222）
-犹太/ Parve清真
特点和优点
美孚FM 101 FM 222属于产品美孚品牌，已经获得了享誉全球的创新和性能卓越。美孚FM 101 FM 222是由埃克森美孚制定的技术人员设计和全球技术支持人员支持。
美孚FM 101 FM 222润滑脂已被专门设计来满足需求的食品加工行业需要优良的耐水性、防锈和润滑油能够提供可靠的负荷区在高剪切条件下。这些润滑脂具有以下功能和潜在的好处：
功能优势和潜在的好处
优良的耐水性和防锈保护，有助于提供卓越的设备保护，在频繁的设备清洗操作
优良的增稠剂剪切稳定性产品具有长期稳定性好，有助于提供油之间持续的再润滑周期
NSF H1注册，DIN 51825认证、犹太/清真工程服务，以满足全球需求，提供多用途的解决方案向世界各地的食品加工行业
通过独立验证注册到的21469产品完整性保证的设施
应用
美孚FM 101 FM 222润滑脂推荐用于多用途润滑的食品加工设备，NSF H1注册是必需的。食品工业包括食品加工、饮料、医药和包装等行业的广泛的文化。
应用包括：
通用旋转设备润滑
输送机轴承
设备集中润滑系统（美孚FM 101）
重载或冲击载荷作用下的抗摩擦滚子轴承
联系和幻灯片接头
Mobilgrease™ FM 101 and FM 222
Grease
Product Description
Mobilgrease™ FM 101 and FM 222 are high performance multi-purpose products designed specifically for the lubrication of food processing machinery. Mobilgrease FM 101 and FM 222 are formulated with components meeting the requirements of CFR 178.3570, Chapter 21, and are NSF registered as H1 classified lubricants. The Mobilgrease FM 101 and FM222 are manufactured at ISO 22000 certified facilities that also meet the requirements of ISO 21469 helping to ensure that the highest levels product integrity are maintained.
Food processing equipment often operates in a variety of environments, covering the extremes of temperatures from oven to freezer operations, as well as a high level of contamination from water, steam and cleaning agents. Mobilgrease FM 101 and FM 222 were developed as multipurpose grease lubricants capable of providing excellent lubrication in all of these environments. Mobilgrease FM 101 and FM 222 are engineered with excellent water resistance to withstand periodic washdown and cleaning operations frequent in the food processing industry. Rust inhibition is a critical property for the industry. Mobilgrease FM 101 and FM 222 are formulated with an excellent rust inhibition package which, working in concert with the water resistance properties, will provide protection against rust. The select base oils coupled with excellent thickener shear stability translates into an ability to provide lubrication over a wide range of speeds, loads and temperatures. Mobilgrease FM 101 and FM 222 are also formulated to handle a variety of loads, exhibiting good protection against wear and shock load conditions.
Mobilgrease FM 101 and FM 222 were designed to meet many global performance and cultural requirements, including:
- NSF H1 Registered
- DIN 51825 KPF1K -20 (for Mobilgrease FM 101)
- DIN 51825 KPF2K-20 (for Mobilgrease FM 222)
- Kosher/Parve
- Halal
Features and Benefits
Mobilgrease FM 101 and FM 222 belong to the Mobilgrease brand of products, which has gained a worldwide reputation for innovation and performance excellence. Mobilgrease FM 101 and FM 222 are designed by ExxonMobil formulation technologists and backed by its worldwide technical support staff.
Mobilgrease FM 101 and FM 222 greases have been designed specifically to meet the needs of the food processing industry that requires excellent water resistance, rust protection and a lubricant able to provide oil to the load zones reliably under high shear conditions. These greases offer the following features and potential benefits:
|
Features
|
Advantages and Potential Benefits
|
|
Excellent water resistance and rust protection
|
Helps provide superb equipment protection during frequent equipment cleaning operations
|
|
Excellent thickener shear stability
|
Product exhibits excellent stability for long periods of time, helping to provide oil more consistently between relubrication cycles
|
|
NSF H1 registered, DIN 51825 certified, Kosher/Parve, Halal
|
Engineered to meet global requirements, presenting a multi-purpose solution to the food processing industry around the world
|
|
Manufactured in facilities registered to ISO 21469
|
Product integrity assurance through independent verification
|
Applications
Mobilgrease FM 101 and FM 222 greases are recommended for multi-purpose lubrication of food processing equipment where NSF H1 registration is required. The food industry includes food processing, beverage, medical and packing industries for a wide range of cultures.
Applications include:
-
General rotating equipment lubrication
-
Conveyor bearings
-
Equipment central lubrication systems (Mobilgrease FM 101)
-
Anti-friction roller bearings under heavy or shock loading
-
Linkages and slides
-
Joints
Specifications and Approvals
|
Mobilgrease FM meets or exceeds the requirements of:
|
FM 101
|
FM 222
|
|
FDA 21 CFR 178.3570
|
X
|
X
|
|
DIN 51825 (2006:06)
|
KPF1K -20
|
KPF2K -20
|
|
Mobilgrease FM has the following builder approvals:
|
FM 101
|
FM 222
|
|
Fives Cincinnati
|
P-72
|
P-64
|
|
Kosher/Parve
|
X
|
X
|
|
Halal
|
X
|
X
|
|
Mobilgrease FM is Registered to the requirement of:
|
FM 101
|
FM 222
|
|
NSF H1
|
X
|
X
|
|
NSF Registration Number
|
141881
|
136449
|
Typical Properties
|
|
Mobilgrease FM 101
|
Mobilgrease FM 222
|
|
NLGI Grade
|
1
|
2
|
|
Thickener Type
|
Aluminum Complex
|
Aluminum Complex
|
|
Color, Visual
|
White
|
White
|
|
Penetration, Worked, 25º C, ASTM D 217, mm/10
|
325
|
280
|
|
Dropping Point, ºC, ASTM D 2265
|
260
|
260
|
|
Viscosity of Oil, ASTM D 445
|
|
|
|
cSt @ 40º C
|
100
|
220
|
|
Penetration Consistency Change, 100,000 Stroke, Change from Worked Pen, ASTM D 1831, mm/10
|
+20
|
+20
|
|
4-Ball Wear Test, ASTM D 2266, Scar, mm
|
0.50
|
0.50
|
|
Corrosion Prevention, ASTM D 1743, Rating
|
Pass
|
Pass
|
|
Copper Strip Corrosion, DIN 51811
|
1b
|
1b
|
|
4-Ball Weld Load, ASTM D 2596, Kg
|
315
|
315
|
|
FE-9 (DIN 51821, A-Unshielded), L50› 100 hours, Deg. C
|
120
|
120
|
 |
