产品展示 >> Mobil Vacuoline 525,528,533,537,546,548美孚威格力循环油
Mobil Vacuoline 525,528,533,537,546,548美孚威格力循环油详细说明 (浏览781次)

 Mobil Vacuoline 525,528,533,537,546,548



美孚威格力循环油

产品描述
产品美孚威格力500系列提供了一个广泛的工业设备多功能润滑油源。润滑油的美孚威格力500系列是高性能重型循环设计为无扭杆米尔斯需要油,但其全面的性能使得它们的循环系统润滑的齿轮和轴承的最佳选择。美孚威格力500系列是专为满足摩根公司的高速无扭Rod Mills的紧迫要求,以及Danielli rod mills的循环油的要求。
它们是由高质量的基础油和专有的添加剂系统,以提供卓越的润湿性,额外的油保留和薄膜保护,防止生锈和腐蚀。美孚威格力500提供了优异的抗氧化和热降解,和高水平的抗磨损保护。他们具备了优良的抗乳化性,使水和其它杂质分离容易从系统油箱中。美孚威格力500系列有六种粘度等级。


应用
这些油主要用于滑动轴承、滚子轴承、平行轴和锥齿轮的润滑。它们是适合作为多用途润滑剂在系统不受冲击负荷,不需要极端的压力性能。美孚威格力500系列具有良好的抗乳化性,保留了严重的水污染条件下。美孚威格力500系列主要应用于采用飞溅,浴和油环润滑和其他所有应用方式的泵,阀门和辅助设备。它们被推荐用于高粘度油的液压系统中。他们特别抵抗长时间的高温暴露的影响,并在短油停留时间的循环系统中表现良好。
典型的应用包括
没有扭曲Rod Mills
中等强度的刺激,锥、螺旋和人字齿轮装置
循环系统
美孚威格力525,528,533也可以用于液压系统采用齿轮、叶片、径向和轴向活塞泵在高粘度抗磨液压油的要求。
一定的压缩机和真空泵处理空气和惰性气体的排放温度不超过150°C,不适合呼吸空气压缩机




Mobil Vacuoline 500

Circulating Oils

Product Description

The Mobil Vacuoline 500 Series family of products provides a versatile lubricant source for a wide range of industrial equipment.  The Mobil Vacuoline 500 Series of lubricants are high performance heavy duty circulating oils designed for the demands of No-Twist Rod mills, however their all round performance makes them a excellent choice for circulation systems lubricating gears and bearings. Mobil Vacuoline 500 Series are designed to meet the critical requirements of the Morgan Construction Company's high speed No-Twist Rod Mills, as well as the circulation oil requirements of Danielli rod mills.
They are formulated from high quality base stocks and a proprietary additive system to provide superior wettability, extra oil retention and thin film protection against rust and corrosion.    Mobil Vacuoline 500 gives excellent resistance to oxidation and thermal degradation, and a high level of protection against wear. They possess excellent demulsibility that permits water and other contaminants to separate readily from the oil in the system reservoir.  The Mobil Vacuoline 500 Series are available in six viscosity grades.



Features and Benefits

The Mobil Vacuoline 500 Series family of products is well known and highly regarded world-wide based on their outstanding performance and the Research and Development expertise and global technical support which stand behind the brand. The highly versatile performance of Mobil Vacuoline 500 Series oils, has made them the choice of many users around the world for many decades.
Mobil Vacuoline 500 series are designed for lubrication of circulation systems of No-Twist Rod Mills, industrial and marine gearboxes, hydraulic systems plus a wide variety of ancillary equipment.

Features Advantages and Potential Benefits
Good protection against rust and corrosion through a balanced high performance lubricant formulation Fewer unscheduled stoppages and lower maintenance costs
Outstanding antiwear performance Excellent protection of critical bearings and gears
Excellent water separation characteristics Rapid separation of water for smooth, efficient operation, reduced downtime and undiminished wear protection
High resistance to oxidation and thermal degradation Long oil charge life and avoidance of costs of unanticipated production interruptions
Multiple application capability Inventory Savings



Applications

These oils are intended primarily for the lubrication of plain bearings, roller bearings, parallel shaft and bevel gearing. They are suitable as multipurpose lubricants in systems not subject to shock loading and which do not require extreme pressure performance. The Mobil Vacuoline 500 series possess good demulsibility that is retained under conditions of severe water contamination.  Mobil Vacuoline 500 series are used in applications using splash, bath and ring oil arrangements and all other application methods involving pumps, valves and auxiliary equipment. They are recommended for use in hydraulic systems where higher viscosity oils are specified. They are particularly resistant to the effects of prolonged high temperature exposure and perform well in circulating systems with short oil residence times.
Typical applications include

  • No Twist Rod Mills
  • Moderate duty spur, bevel, helical and herringbone gear units
  • Circulating systems
  • Mobil Vacuoline 525, 528, 533 can also be used in hydraulic systems employing gear, vane, radial and axial piston pumps where high viscosity anti-wear hydraulic fluids are required.
  • Certain compressors and vacuum pumps handling air and inert gases provided the discharge temperatures do not exceed 150oC , not suitable for breathing air compressors



Specifications and Approvals

Mobil Vacuoline 500 Series meets or exceeds the requirements of: 525 528 533 537 546 548
Morgan Construction Company’s “No-Twist® Rod Mill Lubricants Specification X
Danieli Type 21-0.002117.R BGV No Twist Stand Block-TMB/TFS Rev 14 X



Typical Properties

Mobil Vacuoline 500 Series 525 528 533 537 546 548
ISO Viscosity Grade - 150 220 320 460 680
Viscosity, ASTM D 445
mm2/s @ 40ºC 89 146 215 309 453 677
mm2/s @ 100ºC 10.7 14.4 18.8 24.4 29.4 36.9
Viscosity Index, ASTM D 2270 99 96 96 96 95 89
Pour Point, ºC, ASTM D 97 -24 -21 -15 -12 -12 -9
Flash Point, ºC, ASTM D 92 264 272 284 288 286 286
Specific Gravity @15.6 ºC kg/l, ASTM D 1298 0.88 0.89 0.89 0.89 0.90 0.92
Demulsibility at 54 ºC, ASTM D 1401, Minutes to 37ml water 15 - - - - -
Demulsibility at 82 ºC, ASTM D1401 Minutes to 3ml - 10 15 20 25 5
Demulsibility for non-EP oils, ASTM D2711, ml water 39 38 36 39 35 36
Rust Protection, ASTM D665
Distilled Water Pass Pass Pass Pass Pass Pass
Sea Water Pass Pass Pass Pass Pass Pass
Foaming Characteristics, ASTM D 892Seq I, II, III; Tendency/Stability, ml/ml
Seq I 10/0 5/0 5/0 10/0 5/0 0/0
Seq II 0/0 0/0 0/0 0/0 0/0 0/0
Seq III 0/0 0/0 0/0 0/0 0/0 0/0
Copper Corrosion, ASTM D130 3 hours @ 100ºC 1A 1A 1A 1A 1A 1A
FZG Gear Test, DIN 51354, Failure Stage 12 12 12 12 12 12
