产品展示 >> Mobil Rarus SHC 1024,1025,1026美孚拉力士1020系列空气压缩机油
Mobil Rarus SHC 1024,1025,1026美孚拉力士1020系列空气压缩机油详细说明 (浏览771次)

美孚拉力士1020系列空气压缩机润滑油



Mobil Rarus SHC 1024,1025,1026


美孚拉力士SHC 1020系列

空气压缩机润滑油

产品描述

美孚拉力士SHC 1020系列是一系列性能卓越的润滑油主要用于严重的负荷喷油回转式螺杆式和叶片式空气压缩机的润滑。 它们特别适用于重度服务,而矿物油基产品不符合,如在经受高最后压缩温度或者延长换油周期是理想的严苛应用的期望。 他们制定与设计专用的无蜡合成烃油和高科技添加剂系统,保证氧化和热降解远远优于矿物油为基础的空气压缩机油卓越的性能。 他们提供优秀的设备保护和可靠性条件下其他空气压缩机油不能满足预期下运行压缩机


应用
美孚拉力士SHC 1020系列润滑油主要用于螺杆式和叶片式压缩机。他们是特别有效,对排气温度高达200ºC.拉力士SHC 1020系列润滑油推荐用于连续高温作业单位与多余的机油降解的历史,可怜的阀门性能或矿床的形成。他们是与压缩机建设中使用传统矿物油的空气压缩机油,但与其他油脂混合所有金属兼容可能降低总的性能。
美孚拉力士SHC 1020系列润滑油是不建议使用的空气压缩机呼吸空气的应用不应该被用在压缩机的排气温度高于产品的闪光点。
以下类型的压缩机的应用已经显示美孚拉力士SHC 1020系列润滑油性能优良:
主要推荐用于旋转螺杆和叶片式空气压缩机
具有喷油冷却的螺杆式压缩机非常有效
在恶劣条件下工作的单位
多级单元与矿物油基产品的过度降解石油的历史
具有关键齿轮和轴承的压缩机系统
固定和移动应用中使用的压缩机



Mobil Rarus SHC™ 1020 Series

Air Compressor Lubricant

Product Description

The Mobil Rarus SHC™ 1020 Series is a line of supreme performance oils primarily intended for the lubrication of severe duty rotary screw and vane air compressors. They are particularly suited for severe service where mineral oil-based products are not meeting expectations such as in severe applications subjected to high final compression temperatures or where extended oil drain intervals are desired. They are formulated with design-specific wax-free synthetic hydrocarbon fluids and a high technology additive system that assures exceptional resistance to oxidation and thermal degradation far superior to mineral oil-based air compressor oils. They provide outstanding equipment protection and reliability for compressors operating under conditions where other air compressor oils are not meeting expectations. Mobil Rarus SHC 1020 Series provide excellent wear protection and outstanding resistance to oxidation and thermal degradation, greatly superior to mineral oils. Their unique formulation provides the ability to reduce maintenance costs through minimising equipment problems and downstream deposits and carryover. Their high viscosity index ensures effective lubrication at high temperatures.
Mobil Rarus SHC 1020 Series lubricants significantly reduce the potential for fires and explosions when compared to mineral oil-based products. They exhibit a virtual absence of deposit formation and high autogeneous ignition temperatures improving both performance and safety. Their exceptional water separating characteristics reduce problems with emulsion formation coalescers and filters reducing the need for frequent maintenance.



Features and Benefits

The use of the Mobil Rarus SHC 1020 Series oils can result in cleaner compressors and lower deposits compared to conventional mineral oils, resulting in longer running periods between maintenance intervals. Their excellent oxidation and thermal stability safely allow extended life capability while controlling sludge and deposit formation. They possess outstanding anti-wear and corrosion protection, which enhances equipment life and performance.

Features Advantages and Potential Benefits
High Performance Synthetic Base Stocks Wide temperature range capability
Significant performance capabilities relative to mineral oils
Improved safety
Extended service life
Outstanding Oxidation and Thermal Stability Reduced coking deposits
Longer oil life
Improved filter life
Lower maintenance costs
High Load-carrying ability Reduced wear of bearings and gears
Excellent Water Separability Less carryover to downstream equipment
Reduced sludge formation in crankcases and discharge lines
Reduced blockage of coalescers, inter- and after-coolers
Less potential for emulsion formation
Effective Rust and Corrosion Protection Improved protection of internal compressor components



Applications

The Mobil Rarus SHC 1020 Series oils are primarily intended for rotary screw and vane compressors. They are particularly effective for continuous high temperature operation with discharge temperatures up to 200º C. Rarus SHC 1020 Series oils are recommended for units with a history of excess oil degradation, poor valve performance or deposit formation. They are compatible with all metals used in compressor construction and with conventional mineral oil-based air compressor oils but admixture with other oils may detract from the total performance capability.
Mobil Rarus SHC 1020 Series oils are not recommended for air compressors used in breathing air applications and should not be used in compressors where the discharge temperature is higher than the product flash point.
The following types of compressor applications have shown excellent performance with the Mobil Rarus SHC 1020 Series oils:

  • Primarily recommended for rotary screw and vane air compressor
  • Very effective in screw type compressors with oil injection cooling
  • Units operating under severe conditions
  • Multistage units with a history of excessive oil degradation from mineral oil-based products
  • Compressor systems with critical gears and bearings
  • Compressors used in stationary and mobile applications



Typical Properties

Mobil Rarus SHC 1020 Series Mobil Rarus SHC 1024 Mobil Rarus SHC 1025 Mobil Rarus SHC 1026
ISO Viscosity Grade 32 46 68
Viscosity, ASTM D 445
cSt @ 40º C 31.5 44 66.6
cSt @ 100º C 5.7 7.2 10.1
Viscosity Index, ASTM D 2270 , min 127 131 136
Copper Strip Corrosion, ASTM D130,24 h @ 100º C 1B 2A 1B
Rust Characteristics Proc A, ASTM D 665 Pass Pass Pass
Pour Point, ASTM D 97, ºC, max -48 -45 -45
Flash Point, ºC, ASTM D 92 245 246 246
Specific Gravity 15º C/15º C, ASTM D 1298 0.846 0.849 0.856
