Mobil Vacmul EDM 3多用途电火花加工液

产品描述

Vacmul电火花加工油是多用途的绝缘液用于所有电火花加工机床正常工作的渗透尤其适用于粗加工，精加工和超精加工工作。 Vacmul电火花加工是专为最高的机器生产率和操作员舒适性的电，放电加工中使用时，也称为电火花腐蚀加工非常纯净的液体。 在这个过程中金属加工金属是从一工件施加在工件和成形电极之间的电位差去除。 Vacmul电火花具有提供均匀的绝缘，然后在击穿电压，以允许控制电极放电的能力。

Vacmul电火花具有粘性，波动性，氧化安定性，热传导特性，低气味，低毒性的正确平衡。 Vacmul电火花加工是一种高度精炼，窄馏分，低粘度流体特别适合于精加工工序，其中一个高品质的完成是必需的。 它的功能是刀具和工件，火花导体，冷却液和冲洗油排屑之间的绝缘体。 Vacmul电火花推荐用于高金属去除率是必需的粗加工和精加工和超精加工工作。

特点和优点

优点及潜在效益

1 限制火灾风险

2 产量增加

3 确保液体/金属接触和减少废品

4 方便查看工件和夹具

5 易于处理和改善车间环境

6 较高的金属去除速率和稳定的电气放电

7 提供均匀的绝缘，更高的精度和表面光洁度

产品特点

1 高闪点

2 通过墨盒和地球极好的过滤

3 高润湿性

4 明亮，干净，无臭。

5 在正常使用低敏感性皮肤

6 非脂肪相比，更粘稠液体。

应用

1 优秀的通过渗透工作的所有电火花机。

2 特别适用于粗加工，精加工和超精加工工作。

 美孚Mobil Vacmul EDM 2电火花加工液Mobil Vacmul EDM 3

Vacmul EDM 2 and 3

Multipurpose Electro Discharge Machining Fluids

Product Description

Vacmul EDM fluids are multipurpose dielectric fluids for use in all discharge machines working by penetration especially for roughing, finishing and superfinishing work. Vacmul EDM is very pure fluid designed for maximum machine productivity and operator comfort when used in electrical-discharge machining, also called spark-erosion machining. In this metalworking process metal is removed from a workpiece by applying a potential difference between the workpiece and a shaped electrode. Vacmul EDM has the ability to provide uniform insulation and then to permit controlled electrical discharge at the breakdown voltage.
Vacmul EDM has the correct balance of viscosity, volatility, oxidation stability, heat transfer characteristics, low odour and low toxicity. Vacmul EDM is a highly refined, narrow-cut, low viscosity fluid specially suited to finishing operations where a high quality finish is required. It functions as an insulator between tool and workpiece, spark conductor, coolant and as a flushing oil for chip removal. Vacmul EDM is recommended for roughing operations where a high metal removal rate is required and for finishing and superfinishing work.

Features and Benefits

Applications

• Excellent for all electro discharge machines that work by penetration.
• Especially suitable for roughing, finishing and superfinishing work.

Typical Properties
